Key Characteristics:
Welding: Steel wires are welded together at each intersection to create a sturdy, rigid structure.
Galvanization: The entire mesh is coated with zinc, either before or after welding, to protect against rust and corrosion.
Durability: The combination of welding and galvanization makes the mesh highly durable and long-lasting.
Versatility: It can be used for various applications, including fencing, enclosures, construction, and more.
Types of galvanization:
Galvanized Before Welding (GBW): The wires are galvanized before being welded. This can result in some zinc burning off during the welding process.
Galvanized After Welding (GAW): The mesh is welded first, and then the entire structure is dipped in a molten zinc bath, creating a strong, protective coating.
Galvanized Welded Wire Mesh Specifications
G.I. welded wire mesh specifications: (closed/round edge)
| Mesh | SWG | Width | Length | Weight |
|---|---|---|---|---|
| 25 mm | 35 | 1 m | 60 m | 22 kg |
| 30 mm | 36 | 1 m | 60 m | 24 kg |
| 30 mm | 35 | 1 m | 60 m | 28 kg |
| 30 mm | 34 | 1 m | 100 feet | 35 kg |
| 40 mm | 37 | 1 m | 100 feet | 18 kg |
| 60 mm | 38 | 1 m | 100 feet | 19 kg |
G.I. welded mesh specifications:
| Mesh | SWG | Width | Length | Weight |
|---|---|---|---|---|
| 1/2 inch | 18 | 4 feet | 50 feet | 18 kg |
| 1/2 inch | 20 | 4 feet | 50 feet | 15 kg |
| 1/2 inch | 18 | 5 feet | 50 feet | 23 kg |
| 1/2 inch | 20 | 5 feet | 50 feet | 18 kg |
| 1/2 inch | 18 | 6 feet | 50 feet | 27 kg |
| 1/2 inch | 20 | 6 feet | 50 feet | 21 kg |
| 3/4 inch | 17 | 4 feet | 50 feet | 20 kg |
| 3/4 inch | 17 | 5 feet | 50 feet | 25 kg |
| 3/4 inch | 17 | 6 feet | 50 feet | 30 kg |
| 1 inch | 16 | 4 feet | 50 feet | 20 kg |
| 1 inch | 16 | 5 feet | 50 feet | 25 kg |
